Lybra Station – Pallet wrapper

The Lybra Station is the essence of efficiency in a pallet wrapper. It has a rotating arm, is hard-wearing and reliable and can be trusted to wrap any pallets in your company. Reduced space – High performance, these are the two variables it offers you.

Based on quality

The Lybra Station is an option with the highest quality materials.

Prepared for heavy and unstable loads

The rotating arm provides stability to a load and gives every guarantee that packaging is completed without damage or falling.

Adapts to your needs

We adapt the machine to your end of line. It occupies just the right amount of space to work and adapts to carriages and different accessories that will make your work experience better. Packaging pallets has never been so easy.

Videos Catalogue Quotation

Video gallery

https://youtu.be/G-qPCbglZRU

Technical specifications
Description
Accesories

EASY INSTALLATION.
INTUITIVE CONTROL PANEL.
NUMBER OF TURNS ADJUSTABLE REINFORCEMENT.
INPUT / OUTPUT ROLLER CONVEYOR.
AUTOMATIC PALLET HEIGHT DETECTION.
SAFETY PROTECTION CE FENCE PROTECTION.
TRUCK PROTECTION.
ADJUSTABLE CARRIAGE SPEED UP/DOWN.
PROGRESSIVE START-UP TO AVOID OVERTURNING THE LOAD.
REINFORCEMENT LAPS IN THE MIDDLE OF THE PALLET.
ALTIMETER FUNCTION (PHOTOCELL EXCLUSION).
99 DIFFERENT PROGRAMS TO SAVE.
ADJUSTABLE STRETCH PANEL (FE, PRS, PS).
CLEAN CUT OF THE FILM.
PALLET COVER FUNCTION (WATERPROOFING).
LYBRA STATION PRESSER WITH PALLET RETENTION.
ELECTRIC DISTRIBUTOR.
HIGH RELIABILITY GEARS.
UNLIMITED MAXIMUM PALLET WEIGHT.
AUTOMATIC CORD DEVICE.
MAXIMUM HEIGHT OF 3,000 MM.

Pallet wrapper based on quality

This automatic stretch film wrapping machine has only the highest quality materials. This can be seen in its gears as well as the electric distributor located in the arm. Rotating at 12 / rpm, it supports loads of up to 2,400 kg with maximum sizes of 1000 × 1200 mm. The Lybra Station is designed to be part of your end of line. This is a fully automatic machine that offers autonomy to the process.

Prepared for heavy and unstable loads

The rotating arm ensures correct handling of palletized loads. Whatever your product, the Lybra Station adapts to measurements, and it also has a control centre that will allow you easy access to all its functions. With the panel you can control the rotation speed, carriage speed, tension or strengthening wrap.

Adaptable to your needs

Like all Atlanta machines, the Lybra Station can incorporate different types of carriages, so using any type of stretch film is not a problem. Film pre-stretched at 150, 200 and up to 250% with PRS in addition to being able to pre-stretch at 120 or 350% with a PS. Looking for something different? This is another of our rotary arm machines.

Envolvedora de palets - Atlanta Stretch - Revolution

UPPER PRESSER There are two clamps - circular or rectangular - that allow the load to be supported to prevent it from overturning during packaging.

STRETCH FILM WELDING SYSTEM Self-adjusting stretch film sealing system for any pallet size.

ROPE SYSTEM If you want to secure your load, Omega allows you to create a rope from the same head. Adjustable height to apply this reinforcement on a pallet.
